Fractional Co2 laser treatment:
Ultrapulse fractional co2 laser emits thousands of deep, tiny focal
spot columns in your skin, called microscopic treatment zones.
These lights penetrate into dermis skin, gasify the tissues around
wrinkles and scars in an instant and make a signal of compounding
collagen like tissues repair, collagen rearrangement ettc to regain
a new fresh and healthy skin of youth.
Gynecology Laser treatment:
Use an articulate arm probe with automatically 360° rotation
technology, producing in 50-70℃ at a controlled depth insider the
vaginal mucosastimulates collagen contraction, restructuring and
regeneration; promotes collagen fiber proliferating, remodeling;
improves vaginal mucosa microcirculation; Increases cell secretion
and dynamic reaction function; Corrects PH value of vaginal
insider; Improves the insider environment; Achieve female private
parts to significant lasting firming, nourishing and restoring
harmonious sexual life.
Application 1 :
CO2 fractional laser for skin tightening , fractional skin
resurfacing , Skin renewing, wrinkle removal, whitening , pore
minimization ;
Acne scar removal one surgery , Smooth burnt scars and surgery
scars, dermabrasion , Remove intractable chloasmas and
pigmentation; etc
Application 2 :
in aesthetic surgery .it is mainly used for cutting on
blepharoplasty , skin tags and ingrown nails , compound nevus and
intra dermal nevus etc
Appliction 3 :
Vaginal rejuvenation,vaginal tighteing,vaginal whitening
Specofocation:
| Laser apparatus | Carbon Dioxide fractional(fraxel) laser /Metal RF tube |
| Laser mode: | TEMoo |
| Power | 30W |
| Max power intensity | 75, 000 W / cm² |
| Radiation time | 0.01 1 sec |
| Aiming beam | Less than 2mW, 635nm red semiconductor laser |
| Condenser focus | f=100mm |
| Pulse energy | 10mj to 100mj is optional for each dot. |
| Wavelength : | 10600nm |
| Laser Work mode | Ultra pulse ,fractional CW |
| Output way | Fractional beam& scan beam |
| Cooling system | Wind cooling with treatment head. Water cooling with machine (glass
tube ) |
| Dot number | at max 2000 dots (glass) at max 3000 dots (radio frequency ) |
| Scan mode | Random, sequence, convergence , diagonal even/oddetc |
| Scan Graphics | Square ,circle ,rectangular ,triangle ,line, and any customized
graphics |
| Spot distance(pitch) | 0.12-1.25mm(adjustable) |
| Spot size | 0.2mm |
| Penetrate depth | 2mm |
| Pulse duration | 0.1-20ms for optional |
| overlay | 1 to 20 times |
| Transmission system(Beam delivery ) | Articulated arm with 7 mirrors |
| Display | 10.4 inch big color touch screen |
| Dimension | 57cm(L)*50cm(W)*125cm(H) |
| Power supply | 220V 50HZ , 110V 60HZ |
| Weight | 51KG |
